Accelnet Plus Micro Modules User Guide
4 C
ONNECTIONS AND
Top view looking down on mounting PC board
For Sockets on User PC Board:
Qty Description
1 Socket Strip
1 Socket Strip
1 Socket Strip
2 Standoff
For Soldering to User PC Board:
Qty Description
1 For J1, refer to this document:
1 Socket Strip
1 Socket Strip
2 Standoff
Copley Controls
W
IRING
Dimensions are in inches [mm]
Mfgr Part Number
Samtec SQT-119-01-G-D
Samtec FLE-132-01-G-DV
Samtec TLE-102-01-G-DV-TR
hex, 13 mm long, M2,5 mm thread
Mfgr Part Number
http://suddendocs.samtec.com/processing/through-hole-printing.pdf
Samtec CLP-132-02-L-D-BE-A-K-TR
Samtec CLT-102-2-G-D-BE
hex, 19 mm long, M 2.5 mm thread
- M
ODULES
Notes
1. J1 signals must be connected for current-
sharing.
2. To determine copper width and thickness for J1
signals refer to specification IPC-2221.
J2: Feedback
(Association Connecting Electronic Industries,
Dual row, 0.050 inch centers
http://www.ipc.org)
64 position female header
3. Standoffs should be connected to etches on pc
SAMTEC FLE-132-01-G-DV-K-TR
board that connect to frame ground for
maximum noise suppression and immunity.
They also provide the PE (Protective Earth)
connection between the heatplate and ground.
Ref Des Remarks
J1 2.00 mm (0.0787 in) pitch
J2 0.050" (1.27 mm) pitch
J3 2.00 mm (0.0787 in) pitch
Ref Des Remarks
J2 0.050" (1.27 mm) pitch
J3 2.00 mm (0.0787 in) pitch
16-01687 Rev 03
J1 Signal Grouping
for current-sharing
