Accelnet Plus Micro Modules User Guide
M M
ICRO ODULES
APV-090-14
APV-090-30
APV-090-50 *
APV-090-50-C *
APV-180-10
APV-180-20
*
Not compatible with APV-EZ-090 board. Use APZ-090-50 or APZ-090-50-C if connectorized version is needed
M M
ICRO ODULES
APZ-090-50
APZ-090-50-C
A
CCESSORIES FOR
APV-EZ-090
APV-EZ-180
APV-EZ-CK
APV-HK
APV-THK
SER-CK
SER-USB-RJ11
Copley Controls
: CAN
OPEN
Accelnet Plus Micro Module CANopen servo drive, 7/14 A, 90 Vdc
Accelnet Plus Micro Module CANopen servo drive, 15/30 A, 90 Vdc
Accelnet Plus Micro Module CANopen servo drive, 25/50 A, 90 Vdc
Accelnet Plus Micro Module CANopen servo drive, 50/50 A, 90 Vdc
Accelnet Plus Micro Module CANopen servo drive, 5/10 A, 180 Vdc
Accelnet Plus Micro Module CANopen servo drive, 10/20 A, 180 Vdc
S : CAN
OLDERED
Accelnet Plus Micro Module CANopen servo drive, 25/50 A, 90 Vdc, soldered to EZ board
Accelnet Plus Micro Module CANopen servo drive, 50/50 A, 90 Vdc, soldered to EZ Development
board
M M
ICRO ODULES
EZ Board (Pluggable for 90V APV modules) Not compatible with APV-090-50 or APV-090-50-C
EZ Board (Pluggable for 180V APV modules)
EZ Board Connector Kit (see below)
Heatsink kit (Pins heatsink, thermal pad, and hardware)
Heatsink kit (Tall Pins heatsink, thermal pad, and hardware)
Serial Cable Kit: 9-Pin Dsub receptacle to 6-pin modular adapter, plus modular cable for EZ board
Serial Interface Cable: USB to RJ11
OPEN
: CAN
OPEN
