Accelnet Plus Micro Modules User Guide
O P
UTPUT OWER
AEV-090-14
Specification
APV-090-14
Peak Current
14
Adc *
Peak Current
9.9
Arms *
Peak Current
Time (s)
Continuous
7
Current Adc**
Continuous
Current Arms 4.95
**
Peak Output
1.26
Power (kW)
Cont. Output
0.63
Power (kW)
Efficiency
Output Type
PWM Ripple
Frequency
Minimum Load
Inductance
* Adc is peak of sine, Arms is RMS of sine
** Heat sinking and/or forced air cooling may be required for continuous output power rating
*** Consult factory for operation with inductance lower than 400 µH
Copley Controls
AEV-090-30 AEV-090-50
APV-090-30 APV-090-50
30 50
21.2 35.4
15 25
10.6 17.7
2.7 4.5
1.35 2.25
>97% @ rated max Vdc and rated continuous current
3-phase MOSFET inverter, 16 kHz center-weighted PWM space-vector modulation
AEV-090-50-C AEZ-090-50
APV-090-50-C APZ-090-50
50 50
35.4 35.4
1
50 25
35.4 17.7
4.5 4.5
4.5 2.25
32 kHz
400 µH line-to-line ***
16-01687 Rev 03
AEZ-090-50-C AEV-180-10
APZ-090-50-C APV-180-10
50 10
35.4 7.07
50 5
35.4 3.54
4.5 1.8
4.5 0.9
Page 12 of 139
AEV-180-20
APV-180-20
20
14.1
10
7.07
3.6
1.8
