Accelnet Plus Micro Modules User Guide
D C
IGITAL OMMAND
Stand-Alone Mode digital POSITION-CONTROL Inputs
AEV-APV work with motion controllers that output pulses to command position.
These formats are supported:
• Step/Direction
• Count-Up/Count-Down (CU/CD)
• A/B Quadrature Encoder
In Step/Direction mode, a pulse-train controls motor position, and the direction is controlled
by a DC level at the Direction input. CU/CD (Count-Up/Count-Down) signals command the
motor to move CW or CCW depending on which input the pulse-train is directed to. The
motor can also be operated in an electronic gearing mode by connecting the inputs to a
quadrature encoder on another motor. In all cases the ratio between input pulses and motor
revolutions is programmable.
STP
DI
STEP/DIRECTION INPUTS
Command Options
Step, Position Positive, Encoder A
Direction, Position Negative, Encoder B
D C
IGITAL OMMAND
Stand-Alone Mode Digital VELOCITY/TORQUE CONTROL Inputs
AEV-APV work with motion controllers that output pulses to command velocity and torque
(current). These formats are supported:
• PWM/Direction
• 50 % PWM
In PWM/Direction mode, a pulse-train with variable duty-cycle controls motor Vel/Trq, and
the polarity or direction is controlled by HI/LO levels at the Direction input.
With 50% PWM operation there is a single signal. A 50% duty cycle produces zero output.
Increasing the duty cycle to 100% produces a full-scale output in one direction and 0% duty
cycle produces a full-scale output in the opposite direction.
Duty 0 100
PWM/DIRECTION INPUTS
Copley Controls
I : P
NPUTS
2 AEV, APV
IN3 C U
IN
C D
SGND
COUNT-UP/COUNT-DOWN INPUTS
I : V
NPUTS
2 AE V, APV
I N 3
P M
I N Direc tion
SGN D
Command Options
PWM Vel/Trq, 50% PWM +/- Vel/Trq
Hi/Lo Direction, No connection
OSITION
2 AE V, APV
IN3
IN
SGND
Signal J2 Pins
IN3 7
IN4 8
, T
ELOCITY ORQUE
Duty 50 50
no connection
50% PWM
16-01687 Rev 03
A
QUAD A/B ENCODER INPUTS
J2 Sgnd Pins (APV)
3,4,18,31,32,33,34,42,
49,50,59,60 (19~24)
2 AE V, APV
I N 3
I N N o unc tion
Sgnd
Signal J2 Pins
IN3 7
IN4 8
2 AE V, APV
IN3
Encode r A
IN Encode r
SGND
*
Page 43 of 139
