1.3

Features

•
PICMG 2.0 CompactPCI Specification R2.1 Compliant
•
PICMG 2.1 CompactPCI Hot Swap Specification R1.0 Compliant
•
Standard 3U form factor
•
Design for Socket-7 Low Power Pentium -MMX CPU
•
Supports up to PPGA Low Power Pentium CPU at 266MHz
•
One 144-pin SO-DIMM socket supports up to 256MB RAM
•
Build-in housing for 2.5" low profile HDD
•
Separable slim type floppy drive module
•
Two on-board EIDE 44-pin connector
•
Build-in two USB ports, two serial ports, one parallel port
•
Separate PS/2 type keyboard and mouse connectors
•
Supports 7 bus -master PCI devices on CompactPCI bus peripheral
slots
•
On-board 10/100Mb Ethernet port by Intel 82559 controller
•
Supports Intel pre-boot execution environment (PXE) for remote boot
•
One DOC socket supports up to 144MB DiskOnChip
•
3 or 2 slots width configurations are available for customized
applications
