2.1

Jumpers on the cPCI-3500A

The jumpers on the cPCI-3500A allow you to configure your CPU module
according to the needs of your applications. If you have doubts about the best
jumper configuration for your needs, contact your dealer or sales
representative. The cPCI-3500A module is constructed from the main board
(which has CPU Socket on it) and the daughter board (which brings out serial
port and parallel port). There are jumpers on both main board and daughter
boards. The following table lists the jumper connectors on cPCI-3500A and
their respective functions.
Board
Main board
Daughter board
Note : There is no jumper for DiskOnChip BIOS expansion address
selection. User can select DOC BIOS expansion address from
CMOS setup. The default expansion address for DOC is located
from D8000h to DFFFFh.
Connector
JP1
JP1, JP2, JP3
Description
CPU Speed Select
Select COM2 Type
Hardware Installation • 9
