3. Long press the HDMI Out 1 Select button for about
1 second or wait 10 seconds to save your changes
and exit EDID mode.
4. Repeat steps 1-3 for each HDMI input if necessary.

Specifications

HDMI Compliance
HDCP Compliance
Resolution
Bandwidth
Input Video Signal
Input DDC signal
Video Compatibility
Deep Color
Audio Output
Power Consumption
Operating Temperature
Operating Humidity
10
HDMI 2.0
HDCP 2.2/1.4
480p@60Hz, 576p@50Hz, 720p@60Hz,
1080p@24/50/60Hz, 4K@24/30Hz,
4K@60Hz YUV 4:2:0, 4K@60Hz YUV 4:4:4
18Gbps
0.5 - 1.0 volts p-p
5 volts p-p (TTL)
HDR10, HDR, Dolby Vision
8bit, 10bit, 12bit
LPCM 7.1/24bit/ 96khz, Dolby Atmos,
DTS-X
12.3W (max)
0 - 40 C (32 to 104 F)
5 to 90% RH (no condensation)
