Introduction; Specifications; Package Contents - gofanco Switcher3P User Manual

Introduction

gofanco 3-Port HDMI Switcher 4K - Black (part# Switcher3P)
allows any of the 3 HDMI sources to be displayed on one
HDMI display and supports ultra-high resolution up to 4K.

Specifications

Spec.
Compliance
Video bandwidth
Video support
Audio support
Connectors
Transmission distance
(4Kx2K @60Hz)
Power cable
Dimensions
Weight

Package Contents

• 3- Port HDMI Switcher 4K - Black
• Power cable
• IR remote control
• IR Receiver Extension cable
• User's guide
HDCP 1.4, 36-bit deep Color, 3D
480p, 720p, 1080i, 1080p@60Hz, 4Kx2K (3840x2160 @60Hz)
Dolby-trueHD, DTS-HD master audio 7.1-channel
Input: HDMI x 3
Output: HDMI x 1
Input: 5m (Max.) for HDMI standard cable_26AWG
Output: 5m (Max.) for HDMI standard cable_26AWG
7.48" (W) x 2.34" (H) x 3.42" (D)
HDMI v1.4
10.2Gbps
DC 5V/0.5A
0.13lbs
3
