Scanning Industrial X-ray Films

ScanWizard Industry is a scanning software designed by Microtek for Industrial
X-ray films scanning used for an industrial purpose. Its user-friendly interface
enables you to easily start the scanning process and finish all the scan jobs.
Refer to the ScanWizard Industry software manual for more details.
1. Follow the procedures for "Positioning Industrial X-ray Film with the Light
2. Launch ScanWizard Industry (either as a stand-alone by clicking the program
3. Click the Overview button to perform a preliminary scan of the image, which
4. Select your image output type in the Type drop-down menu.
5. Select your desired image output
6. Select the Scan Frame tool (
28 NDT-2000 User's Manual
Shield" to load the film into the digitizer's Feed Tray.
icon, or by using the "File-Import" or "Scan" command from an application
program).
NOTE: If it is your first time to turn on
the digitizer and to launch the program,
if the Light Shield is not pull up, the
program will prompt a window to remind
you. Bring up the Light Shield and click
the Calibration button. Then, the digitizer
will start to calibrate.
When the calibration is done, click the
OK button to bring in main windows of
ScanWizard Industry program.
To skip the reminding window, pull up
the Light Shield before turning on the
digitizer.
will appear in the Preview window.
– Select Gray Scale to scan the image
in 8-bit grayscale. This is also the
default setting of the software
program.
– Select Gray Scale (16-bit) to scan the
image in 16-bit grayscale.
resolution in the Resolution drop-down
menu. The default setting is 300 dpi.
the Toolbar in the Preview window,
and choose the area to be scanned
by dragging a rectangle around it.
You will see a flashing frame (marquee)
around the selected area.
) from
