Scanning X-ray Films by Using the Auto Film Feeder (AFF)

1. Load the films to be scanned into the tray of the AFF.
2. Launch ScanWizard Industry (either as a stand-alone by clicking the program
3. Click the Scan Process Tool button and then choose "Auto Film Feeder" from
4. Click the Overview button to perform a preliminary scan of the image, which
5. Select your image output type as Gray Scale or Gray Scale (16-bit) from the
6. Select your desired image output resolution in the Resolution drop-down
7. Select the Scan Frame tool (
8. Select your desired image quality (3.5D, 4.0D, or 4.5D) from the Density
9. If necessary, select your desired scan mode (Standard Mode or Speed
10. Click the Scan button in the Preview window to scan all the films loaded on
NOTE: When scanning with the AFF function, the height limit for the scan frame
is 17". If the value of the height in the scan frame is larger than 17, it will be set
back to 17" automatically by the system.
54 NDT-2000 User's Manual
Make sure that the Light Shield has been pulled up if the width of the film is
large than 10.24" (26 cm); otherwise, pull it down.
icon on the desktop, or by using the "File-Import" or "Scan" command from
an application program).
the appearing drop-down menu.
will appear in the Preview window.
Type drop-down menu.
menu. The recommended resolution is 300 dpi or above.
choose the area to be scanned by dragging a rectangle around it. You will
see a flashing frame (marquee) around the selected area.
drop-down menu for the current scan job, based on the needs/image quality
requirements of the inspection.
Mode) from the Scan Mode drop-down menu to scan film based on the
requirements.
the tray of the AFF.
• If ScanWizard Industry is launched as a stand-alone program, a window
"Scan To: Save As" dialog box will appear. Click the Save button; then,
the scanned image can be saved into your selected folder or sent to your
selected application.
To view the scanned image, double click the "Industry Images" icon on
your desktop (default folder assigned by the software), or retrieve it from
your assigned folder.
• If ScanWizard Industry is launched as a Plug-In from an image-editing
program, the scanned image is delivered to your application, where the
image can be saved, viewed, or modified further.
) from the Toolbar in the Preview window, and
