Quick Start Guide
Easy steps to getting started
1
Unpack Contents
Unpack your digitizer package and check for
major components.
1. Medi-7000
2. Output Tray (Main part)
3. Extension part of Output Tray
4. Feed Tray
5. Power Cord
6. Software CD
7. Hi-Speed USB Cable
2
Install Software
Important: You must install software before connecting
your digitizer. Always close any open programs and turn
off Anti-virus utilities before installing software.
A. Turn on your computer.
B. Place the Microtek CD-ROM into the CD-ROM drive, and follow the on-screen
instructions to install the driver and software.
C. Restart your computer at the end of installation.
NOTE: If the Software Installer screen does not come up automatically, double-click the following in
succession: "My Computer"; the CD-ROM icon; then cdsetup.exe to start the installer program.
Copyright © 2013
Microtek International, Inc.
I49-004575 B, September 2013
4
1
http://www.microtek.com
3
1
5
6
2
7
Advertisement
Table of Contents
Related Manuals for Microtek Medi-7000
Summary of Contents for Microtek Medi-7000
-
Page 1: Quick Start Guide
Anti-virus utilities before installing software. A. Turn on your computer. B. Place the Microtek CD-ROM into the CD-ROM drive, and follow the on-screen instructions to install the driver and software. C. Restart your computer at the end of installation. - Page 2 Feed Tray Install Digitizer Feed Tray Holes Install Feed Tray A. Look for two sets of the Feed Tray Holes at both ends of the front-top of the digitizer. B. Insert and push down both sides of the Feed Tray into its compartment holes, making sure the Feed Tray snaps into place.
- Page 3 Connect Digitizer To the power cord A. Connect the power cord to the left side of the digitizer. B. Plug one end of the power cord into a wall outlet or other power source. To the Hi-Speed USB cable C. Connect one end of the Hi-Speed USB cable to your computer. D.
-
Page 4: Scanning Basics
Double-click the “MSmart Images” icon on the desktop to view the images; or, retrieve it from your preferred folder. NOTE: Your scan job can be carried out automatically with your own scanning settings. For details on how to customize your scanning settings, refer to the Medi-7000 User’s Manual. Settings window Preview window... - Page 5 Fixing Film Jams 1. Open the front cover by pressing the Release buttons on the both sides of the front cover. Release button 2. After opening the front cover, let the jammed film fall into the Output Tray and Front cover then remove it.
- Page 6 Scanning lamp or image sensor circuit failure. Please don't select fast preview or draft scan!” This error message appears when the luminance of lamps is insufficient or surpassed. Click OK first; then contact the professional technician or call the Microtek Customer Service Department for the further help.
- Page 7 After you finish the installation of software, if you found that the installed drivers and software cannot run your product or your computer system properly later, please go to the Microtek Download Service site at ww7.microtek.com.tw/service.php to download and install any updates you may require.
