Installing and Connecting the Auto Film Feeder (AFF)

You can use either the Auto Film Feeder (AFF) or the Feed Tray for one time with
your digitizer; therefore, before mounting the AFF onto your digitizer, make sure
that the Feed Tray has been removed out from the digitizer and the digitizer's
power is off.
Follow the steps below to install the AFF.
1. Look for two sets of the Feed Tray
2. Insert and push down both sides of
48 NDT-2000 User's Manual
Lift up the Feed Tray
and remove it from the
digitizer before installing
the AFF onto the
digitizer.
Holes at both ends of the front-top of
the digitizer.
the AFF into its compartment holes,
making sure the AFF snaps into place.
AFF
