Optional Multi-channel Film Feeder (MFF)

The Multi-channel Film Feeder (MFF) is an optional accessory for the NDT-2000
digitizer. The MFF only works with X-ray film, allowing to scan 2-3 sheets of
60 mm, 70 mm, 80 mm, 90 mm, 100 mm, 120 mm, 140 mm, 3.3 inch and 4.5
inch in width films at one time.
After unpacking the MFF package, check for the items shown below.
Specifications of MFF:
–
–
–
The coming section describes how to install the MFF on the NDT-2000 and how
to scan X-ray films by using the MFF.
56 NDT-2000 User's Manual
Screw & Washer Sets
Back Supports
Base Tray
Film Capacity : 3 sheets of 60 mm, 70 mm, 80 mm, 90 mm, 100 mm, 3.3
inch and 4.5 inch in width films at one time; or, 2 sheets of 120 mm and
140 mm in width films at one time.
Dimension: 700 (L) x 420 (W) x 255 (H) mm
Weight: 4.45 kg
Film-rolling
Rack
Quick-lock Nuts
MFF Mask Kit
Multi-channel Film Tray
