Chapter 4: BIOS Setup
PCH-IO Configuration
Aptio Setup - AMI
Chipset
PCH-IO Configuration
► PCI Express Configuration
SATA Configuration
►
State After G3 [S0 State]
Version 2.21.1278 Copyright (C) 2021 AMI
High Precision Timer
Enables or disables high precision event timer.
Restore AC Power Loss
Select the AC power state when power is re-applied after a power failure.
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
PCI Express Configuration
This section is used to configure PCI Express configuration.
PCI Express
Configuration settings
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
PCI Express Root Port 1, 2, 3, 7
Settings for PCI Express root port 1, 2, 3 and 7.
39
Aptio Setup - AMI
Chipset
PCI Express Configuration
► PCI Express Root Port 1
► PCI Express Root Port 2
► PCI Express Root Port 3
► PCI Express Root Port 7
Version 2.21.1278 Copyright (C) 2021 AMI
PCI Express Root Port
Settings.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
