Chapter 3: System Setup
3. Attach the RF cables onto the module and mount the other ends ot the
cables to the antenna holes on the chassis.
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
4. Insert the 2 rings (ring 1 then ring 2) into the Wi-Fi antenna jacks. Please
remove the two antenna hole covers on the front panel before installing
the antenna jacks.
Ring 2
20
Ring 1
ISA 140 User Manual
