Chapter 3: System Setup

Installing SO-DIMM Memory Modules

1. With the chassis cover removed, install a memory module in the
SO-DIMM socket. Push the module down until the clips on both sides of
the socket lock into position. The gold-plated connector on the edge of
the module will almost completely disappear inside the socket.
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
2. Push the module down until the clips on both sides of the socket lock
into position. You will hear a distinctive "click" sound, indicating the
module is correctly locked into position.
SO-DIMM
