Chapter 2: Jumpers and Connectors
Block Diagram
M.2 2242
storage
DDR4 SODIMMx1
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
MiniPCIe slot for WiFi(AP/Client)
1xUSB2.0
1xPCIe
SATA III
eMMC
Elkhart Lake
2 cores
PCIex1
PCIex1
PCIex1
i210
i210
i210
1512
1 pair bypass
TSN
4
2 (1512, TSN)
5
3 (i210)
6x 1GbE RJ45 include 1x OOB port
M.2 3042 B key for 4G LTE
1xUSB2.0
SPI
SGMII
RGMII1
RGMII0
1512
1512
OOB
TSN
0 (OOB)
1 (TSN)
14
TPM2.0
Super IO
F81804U
eSPI
USB3.0x2
2xUSB3.0
RJ45 Console
HDMI
