Chapter 2: Jumpers and Connectors

Jumpers

CMOS Clear

Connector type: 1x3 3-pin header, 2.54mm pitch

Connector location: JP1, JP3
1 3
JP1
Pin Definition
1 SRTC_RST_N
2 GND
3 NC
JP3
Pin Definition
1 NC
2 GND
3 RTC_RST_N
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.

Programmable for MCU

Connector type: 1x5 5-pin header, 2.54mm pitch
Connector location: JP2
1 5
Pin Definition
1 MCU1_NMCLR
3 GND
5 MCU1_PCEC
9
Pin Definition
2 VDD_MCU
4 MCU1_PGED
