Industrial Electronic Devices
CHARACTERISTICS:
The "HD67458" series are rugged devices used to interface EtherNet/IP Master with a NMEA 2000 network.
With his particular enclosure, equipped with four fixing lugs, makes available the mounting of the device in any plane surface (horizontal,
vertical, oblique).
It is possible to have the device varnished or totally resined and also in both cases with "Mini-Fit®" connectors or "AMP SuperSeal 1.5"
connectors. If is resined, the enclosure, like the "AMP SuperSeal 1.5" connectors, is waterproof (IP63).
The device have these characteristics:
Triple 4kV isolation between Power Supply / Ethernet / CAN;
Varnished / Resined (optionally);
Wide power supply input range: 8...26V AC | 10...40V DC;
Mini-Fit® / AMP SuperSeal 1.5 connectors;
Metal enclosure with fixing lugs;
Possibility to use Metal hose clamps for fixing it without using lugs;
Microprocessor for data control;
Wide temperature range: -40°C / 105°C (-40°F / 221°F).
CONFIGURATION:
You need Compositor SW67458 software on your PC in order to perform the following:
Define the parameter of the EtherNet/IP bus;
Define the parameter of the NMEA 2000 bus;
Define the list of NMEA2000 messages in reception and transmission
Update the Firmware and/or the Project.
ADFweb.com Srl – IT31010 – Mareno – Treviso
User Manual NMEA 2000 / EtherNet/IP - Converter
Document code: MN67458_ENG
;
INFO:
www.adfweb.com
Revision 1.000
Page 7 of 31
Phone +39.0438.30.91.31
