58 . Spectrum RX I Getting Started Guide
6. Adjust the screw until the energy bar on the screen is at the maximum
obtainable.
NOTE: The adjustment is sensitive. The energy should reach the maximum
within one quarter-turn of the key.
7. Insert the hexagonal wrench in the hole on the right, also at 6°. The
wrench goes down farther into this opening than into the other.
8. Adjust this screw also, to give maximum energy.
9. Repeat steps 5 through 8 until you are sure that the energy throughput is
maximized.
NOTE: Typically, the maximum energy will be between 90 and 120 units. It
should take about three repeats of steps 5 through 8 to achieve an
alignment to within 1 unit of the maximum observed value.
10. Refit the inserts in the holes by pressing down and twisting them into
position.
11. Press STOP.
Ready For Next Command returns.
