These safety warnings are provided to ensure the safety of personnel
and proper operation of the instrument.
• Read the instruction manual completely and follow all the safety infor-
mation before attempting to use or service this instrument.
• Never exceed the maximum working voltage ratings given.
• NEVER open the back of the instrument while connected to any circuit
or input.
• Always inspect the instrument accessories and leads prior to use.
Replace any defective parts immediately with factory parts.
1.1

International Electrical Symbols

Signifies that the instrument is protected by double or reinforced insulation.
Indicates a WARNING and that the operator must refer to the user manual for instructions
before operating the instrument. Failure to follow or carry out any instructions preceded
by this symbol in the user manual may result in personnel injury or damage to the
instrument and installations.
Risk of electric shock. The voltage at parts marked with this symbol may be dangerous.
Refers to a type A current sensor. This symbol signifies that application around and
removal from HAZARDOUS LIVE conductors is permitted.
Refers to a type B current sensor. Do not apply around or remove from HAZARDOUS
LIVE conductors without additional protective means (de-energizing the circuit or
wearing protective clothing suitable for high voltage work).
In conformity with WEEE 2002/96/EC
®
Simple Logger II Model L261
CHAPTER 1

INTRODUCTION

WARNING
3
