Installing the SmartSensor V

In this chapter

Installing the SmartSensor V is quick and easy. Once installed, the SmartSensor V requires

little or no on-site maintenance. This chapter will describe the installation process, includ-

ing how to attach the sensor to the pole and how to correctly align the sensor.

Selecting the Offset and Mounting Height

After selecting a mounting location within the recommended range of offsets (see introduc-

tion), use Table 1.1 to select a mounting height. See Figure 1.1 for an illustration of what is

meant by offset and mounting height.

˽ Selecting the Offset and Mounting Height

˽ Attaching the Mount Bracket to the Pole

˽ Attaching the Sensor to the Mount Bracket

˽ Aligning the Sensor to the Roadway

˽ Applying Silicon Dielectric Compound

˽ Connecting the 8-conductor Cable
