Table Of Contents - Wavetronix SmartSensor V User Manual

Contents
Chapter 1
Part I
Chapter 2
Chapter 3
Part II
Chapter 4
Chapter 5
Introduction
SmartSensor V Package 6 • Selecting a Mounting Location 6
Installing the SmartSensor V
Installing the SmartSensor V
Selecting the Offset and Mounting Height 13 • Attaching the
Mount Bracket to the Pole 15 • Attaching the Sensor to the
Mount Bracket 16 • Aligning the Sensor to the Roadway 17 •
Applying Silicon Dielectric Compound 17 • Connecting the
8-conductor Cable 17
Connecting Power and Surge Protection
Connecting Lightning Surge Protection 19 • Grounding 21 •
Connecting AC Power Conversion 22 • Connecting DC Power
25 • Wiring Communication 27
Using SmartSensor Manager
Getting Started with SmartSensor Manager
Installing SmartSensor Manager 31 • About Screen 32 • Table
of Contents 32
Communication
Serial Connection 36 • Modem Connection 37 • Internet
Connection 39 • Firmware Upload 41 • Connection Properties
43 • Address Book 43 • Communication Error 45
5
13
19
31
35
