Default Configuration

The EZ-KIT Lite evaluation system contains ESD (electrostatic
discharge) sensitive devices. Electrostatic charges readily accumu-
late on the human body and equipment and can discharge without
detection. Permanent damage may occur on devices subjected to
high-energy discharges. Proper ESD precautions are recommended
to avoid performance degradation or loss of functionality. Store
unused EZ-KIT Lite boards in the protective shipping package.
The ADSP-21364 EZ-KIT Lite board is designed to run outside your per-
sonal computer as a standalone unit. You do not have to open your
computer case.
When removing the EZ-KIT Lite board from the package, handle the
board carefully to avoid the discharge of static electricity, which may dam-
age some components.
connector locations, and LEDs used in installation. Confirm that your
board is set up in the default configuration before continuing.
ADSP-21364 EZ-KIT Lite Evaluation System Manual
Using the ADSP-21364 EZ-KIT Lite
Figure 1-1 shows the default DIP switch,
