Expansion Interface (J1–J3)
Three board-to-board connectors (
processor's peripheral interfaces. The connectors are located at the bottom
of the board. For more information about the interface, see
Interface" on page
tact Samtec.
Part Description
90-position 0.05" spacing,SMT
90-position 0.05" spacing
(through hole)
90-position 0.05" spacing
(surface mount)
90-position 0.05" spacing
(low cost)
Audio In RCA Connector (J4)
Part Description
Two-channel right angle RCA jack
Two-channel RCA interconnect
cable
ADSP-21364 EZ-KIT Lite Evaluation System Manual
ADSP-21364 EZ-KIT Lite Hardware Reference
J1–3
2-7. For the connectors availability and pricing, con-
Manufacturer
SAMTEC
Mating Connectors
SAMTEC
SAMTEC
SAMTEC
Manufacturer
SWITCHCRAFT
Mating Cable
MONSTER CABLE
) provide signals for most of the
Part Number
SFC-145-T2-F-D-A
TFM-145-x1 series
TFM-145-x2 series
TFC-145 series
Part Number
PJRAS1X2S02X
BI100-1M
"Expansion
2-17
