1. Introduction

1. Introduction

About the Products

These products are two inputs (LVDS or DVI-D sign) compatible, panel-mounted, TFT LCD display unit
for use with host computers such as the CONTEC IPC series and SBCs (single board computers).
Touch panel is available via RS-232C (Built-in video cable) or USB connection.
Because its panel attachment is compatible with the predecessor IPC-DT60(panel mount type61)
series, they are transposable.

Features

- LVDS and DVI-D inputs supported panel mount TFT LCD display
LVDS and DVI-D inputs, that are less affected by the interference of noise, are supported for host
computer connection. Because of the digital signal input, up to 5 m of cable length is available. The
video signal and touch panel signal can be connected with one cable depending on the host PC to be
connected.
In addition, the front part of the product has adopted a lightweight aluminum material.
- Touch panel enables keyboard-less operation.
These products have analog touch panel enabling mouse emulation using driver software.
Touch panel is available via USB connection or optional display cable (built-in video signal and touch
panel signal).
- The panel attachment size compatible with IPC-DT60(panel mount type61) series
Because its panel attachment is compatible with the predecessor IPC-DT60(panel mount type61)
series, they are transposable.
- Front side in IP65-rated dustproof/drip-proof structure
Front side in IP65-rated dustproof/drip-proof structure
- AC adapter, stand and connection cable is available as option.
An optional AC adapter (IPC-ACAP12-02), stand (IPC-SND-03) and connection cable is available to
run the display from the AC power supply, to use as a desktop display and for connection to the host
computer.
* For more details on host computer or option of this product, contact your retailer.
1
FPD-L71ST-DC1, FPD-H71XT-DC1
