1. Introduction

1. Introduction

About the Product

These products are two inputs (LVDS or DVI-D sign) compatible, embedded type (open-framed), TFT
LCD display unit for use with host computers such as the CONTEC IPC series and SBCs (single board
computers).
Touch panel is available via RS-232C (Built-in video cable) or USB connection.
Because its panel attachment is compatible with the predecessor IPC-DT/x65 series, they are
transposable.

Features

- LVDS and DVI-D inputs supported embedded type TFT LCD display
LVDS and DVI-D inputs, that are less affected by the interference of noise, are supported for host
computer connection. Because of the digital signal input, up to 5 m of cable length is available. The
video signal and touch panel signal can be connected with one cable depending on the host PC to be
connected.
Full-bright, wide-angle-of-visibility type of liquid crystals capable of displaying up to 16,777,216 colors
on the 15 inches and 262,144 colors on the 12.1/10.4 inches.
- Touch panel enables keyboard-less operation.
These products have analog touch panel enabling mouse emulation using driver software.
Touch panel is available via USB connection or optional display cable (built-in video signal and touch
panel signal).
- The panel attachment size compatible with IPC-DT/x65 series
Because its panel attachment is compatible with the predecessor IPC-DT/x65 series, they are
transposable.
- Front side that can be meet the IP65-rated drip-proof specification using the bundled waterproof
packing
Attaching the panel with a waterproof packing, the front side can be meet the IP65-rated drip-proof
specification.
- AC adapter and connection cable is available as option.
An optional AC adapter (IPC-ACAP12-02) and connection cable is available to run the display from the
AC power supply and to use for connection to the host computer.
* For more details on host computer or option of this product, contact your retailer.
1
FPD-M75VT-DC1, FPD-L75ST-DC1, FPD-H75XT-DC1
