6. Power Supply Connection
Figure 6.1. Graph of Rise Time of Power Supply
AC Adapter Jack
The AC adapter jack is used to connect the AC adapter [IPC-ACAP12-01] available as an option. Do
not connect any AC adapter other than the option.
+12V
GND
Figure 6.2. AC Adapter Jack
AC adapter code removal prevention fitting
(1) Insert the plug of AC Adapter.
(2) Tighten the screws on the attachment fitting.
Figure 6.3. Code Removal Prevention Fitting
30
FPD-L71ST-DC1, FPD-H71XT-DC1
