9. Display Mode
This equipment supports the following display modes:
Video Number of
pixels (dot)
mode
VGA 640 x 480
VESA 800 x 600
VESA 1024 x 768
x: Display is unavailable
Ο: Display available (Depending on the scaling function of host PC)
: Recommended resolution (mode)
CAUTION
- The number of display pixels in the LCD is 640 x 480 dots on FPD-S71VT-DC1 model, 800 x 600
dots on FPD-L71ST-DC1 model and 1024 x 768 dots on the FPD-H71XT-DC1 model.
When the input has a resolution lower than the number of display pixels of each model whether or
not an auto scaling function from the host PC exists, etc.,. Note, in this case, that the display
quality is therefore degraded in clearness compared to the screen displayed at the resolution that
matches the number of display pixels of the LCD and the display area is not displayed in the full
screen because it exists in the center of screen.
- The screen will not possible to be likely to display correctly if the resolution and frequency do not
match one of the supported display modes.
FPD-L71ST-DC1, FPD-H71XT-DC1
Horizontal
Dot clock
frequency
(MHz)
(kHz)
25.18 31.47
40.00 37.88
65.00 48.36
Vertical
frequency
(Hz)
60
60 x
60 x
9. Display Mode
Display
Ο Ο
Ο
x
