5. Connection to the Host Computer
When connecting to a SPI-855x/IPC-BX8x0 series
The LVDS output is set to Disabled by default. It is required to change the LVDS output to Enabled
via BIOS menu.
1. Select "Video Features" from "Advanced" menu.
Main Advanced Security Power PC_Health Boot Exit
Reset Configuration Data:
Installed O/S:
Large Disk Access Mode:
>Cache Memory Features
>Memory Features
>PCI Features
>IDE Features
>Video Features
>LAN Features
>USB Features
>Audio Features
>IO Features
>Keyboard Features
>Boot Features
Figure 5.1. Advanced Menu Screen
22
[Yes]
[WinXP]
[DOS]
FPD-L71ST-DC1, FPD-H71XT-DC1
