Chapter 7: Board Specifications

7.1 INTRODUCTION

This chapter describes the specifications for the development board and the components on the
board. It also describes the optimum operating and storage environment that ensures that the
development board will operate at the performance levels described in the CS89712 Data Sheet.

7.2 PHYSICAL SPECIFICATION

The development board has the physical characteristics described in the following sections.
7.2.1

Printed Circuit Board (PCB)

7.2.1.1. PCB Form Factor

The PCB form factor is 19.6 cm x 20.2 cm (7.7" x 8"). A picture of the board is shown in
3, "Layout of CS89712 Development Board with Major Board Components Identified,"

7.2.1.2. PCB Construction Materials

The PCB is constructed from materials with a flame rating of 94V0. This rating meets the
self-extinguishing characteristics required by safety agencies in countries of sale.

7.2.1.3. Connector Characteristics

Processor Daughter Module Headers (J4-J7)
The four connectors intended for use as daughter module headers are arranged around the processor
and are intended for future processor development. Example part: Samtec - TSW-125-07-G-D.
Expansion Header (J22)
These headers bring out the pins for the keyboard, LCD, and other interfaces. The headers are 0.100"
spacing, 0.025" square posts. Example part: Samtec TSW-120-07-G-S.
Ethernet (J3)
The Ethernet connector used in this design is a standard right angle 10Base-T RJ45. Example part:
CorCom - RJ45-8L2-S.
Serial Ports (J8, J9)
The serial port connectors are male, right angle standard density 9-contact DSUBs. Example part:
