Chapter 5: Using the Development Board
Software

5.1 INTRODUCTION TO THE DEVELOPMENT BOARD SOFTWARE

You can communicate with the CS89712 Development Board and control its features using any of
the tools sets listed below. These tool sets are supplied with the kit, along with everything needed
to connect them to the CDB89712. Green Hills Multi 2000 runs on a PC, which is connected to the
CDB89712 via the PC parallel port through the Wiggler, which is connected to the JTAG connector
JP21. The ARM tools run on a PC that is connected to the CDB89712 through a serial cable
connected between the COM port on the PC and the Serial Port 1 connector (J9) on the development
board. BlueCat Tools run on a PC, which is connected to the CDB89712 through a serial cable
connected between the COM port on the PC and the Serial Port 0 (J8) connector on the development
board.
Once you set up any of these environments, you have a complete integrated environment to assess
the features and functions of the CS89712 and the peripherals designed on the board.
5.1.1

Green Hills Multi 2000

Included in the CD-ROM is a 30-day evaluation copy of Green Hills Multi 2000. This software
contains the MULTI 2000 Integrated Development Environment; C/C++ Optimizing Compilers;
Instruction Set Simulator; MULTI Multimedia Demonstration (Windows 9x/NT Only); and
Documentation in PDF format. The CD-ROM has an excellent "Getting Started Guide" provided by
Green Hills. This includes a description of how to get started developing programs using the "hello
world" program as an example.

5.1.1.1. Ice_boot

Ice_boot must be loaded into the Flash memory before the Green Hills tools can be installed. The
board is shipped with Ice_boot installed. Should it become necessary to reload Ice_boot, use the
following procedure:
Power down the board, install a jumper on JP31, power up the board, then press POR (S3).
Open a DOS window, change to the directory "C:\Green\Examples\cirrus_cs89712\ice_boot" and
type:
download ice_boot.rom
Press the Wakeup button (S4).
When the download process is complete, the PC will display the message:
Successfully downloaded ice_boot.rom
Power down the board, remove JP31, then power up the board. Press POR, wait 2 seconds, then press
