4.3 CS89712 DEVELOPMENT BOARD LAYOUT

Figure 4-3 shows the layout of the CDB89712, Rev. A and Rev. B:
ICE
Connectors
Reset,
Wakeup
Buttons
Power
Manage-
ment
Switches
Prototype
Area
Expansion
Headers

Figure 4-3. Layout of CS89712 Development Board with Major Board Components Identified

DS502UM2
Ethernet
Flash memory
Connector
IrDA Port
UART2 /
Serial Port 1
SDRAM
UART1 /
Power
Serial Port 0
Connector
CDB89712
Prototype
Area
CS89712
Power
Switch
4-3
