CDB89712
development board to either COM1 or COM2 of the host PC. See
"Angel Debug Monitor" on page 2
for more information about the Angel debug monitor software.
The pin connections for the null modem connector are shown in
Figure
4-2.

Figure 4-2. Null Modem Cable Wiring

4-2
DS502UM2
