Facp/Optional Power Supply Hook-Up Diagrams - Altronix Maximal FD Series Installation Manual

Fig. 5 Polarity reversal input from FACP signaling
circuit output (polarity is referenced in
alarm condition):
CUT
JUMPER
FACP
TRG
Fig. 6 Normally Open: Non-Latching FACP
trigger input:
FACP
TRG
Fig. 8 Normally Closed: Non-Latching FACP
trigger input:
FACP
TRG
- 12 -
FACP Hook-Up Diagrams:
FACP
OUTPUT EOL
FROM FACP
--
OUTPUT
+
CIRCUIT
N.O. TRIGGER
INPUT
N.C. DRY
TRIGGER
INPUT
JUMPER
Fig. 7 Normally Open FACP Latching trigger
input with reset
(This output has not been evaluated by UL):
FACP
TRG
Fig. 9 Normally Closed: Latching FACP trigger
input with reset
(This output has not been evaluated by UL):
FACP
TRG
Maximal3FD/5FD/7FD Series (PTC) Installation Guide
N.O.
TRIGGER
INPUT
N.C. RESET
SWITCH
JUMPER
N.C. RESET
SWITCH
N.C. TRIGGER
JUMPER
INPUT
