Facp/Optional Power Supply Hook-Up Diagrams - Altronix Maximal FD Series Installation Manual

Fig. 5 Optional hook-up using two (2) isolated
power supply inputs (Only applicable on
Maximal11FD, not evaluated by UL):
CUT JUMPERS
J1 AND J2
J2 J1
Fig. 7 Normally Open: Non-Latching FACP
trigger input:
FACP
TRG
Fig. 9 Normally Closed: Non-Latching FACP
trigger input:
FACP
TRG
- 12 -
FACP Hook-Up Diagrams:
ISOLATED POWER INPUT
12 OR 24 VAC OR VDC
(ACM8 POWER)
ISOLATED POWER INPUT
12 OR 24 VAC OR VDC
(LOCK POWER)
N.O. TRIGGER
INPUT
N.C. DRY
TRIGGER
INPUT
JUMPER
Maximal11FD/33FD/55FD/75FD/77FD Series Access Power Controllers (PTC) Installation Guide
Fig. 6 Polarity reversal input from FACP
signaling circuit output (polarity is
referenced in alarm condition):
CUT
JUMPER
FACP
TRG
Fig. 8 Normally Open FACP Latching trigger
input with reset:
FACP
TRG
Fig. 10 Normally Closed: Latching FACP trigger
input with reset:
FACP
TRG
FACP
OUTPUT EOL
FROM FACP
--
OUTPUT
+
CIRCUIT
N.O.
TRIGGER
INPUT
N.C. RESET
SWITCH
JUMPER
N.C. RESET
SWITCH
N.C. TRIGGER
JUMPER
INPUT
