Important note:

Internal Adjustment/Calibration

- Make sure that the menu code "1 9 3 - internal adjustment/calibration
accessible" is set (see page 13, "Balance Operating Menu Settings)".
- Tare the balance by pressing »
adjustment/calibration function.
- The built-in, motorized adjustment/calibration weight is applied and then
removed automatically, the weight value is stored, and the balance then
returns to the standard weighing mode.
- After completing the adjustment, reset the "1 9" code setting in the balance
operating menu.

Opening and Closing the Balance

Opening the Balance

If you remove the seal (warranty sticker), your balance is no longer covered
under the warranty.
- Disconnect the balance from the power supply.
- Remove all movable parts from the balance, depending on the model, e.g.
weighing pan (102,107,108), pan support, (104) glass draft shield
cylinder (106), etc.
- Remove the screw (111) from the base plate.
- Carefully lift the upper part of the housing (110) from the back, push it
forward and lift it off.

Closing the Balance

- Place the upper part of the housing (110) on the balance and fasten it with
the screw (111).
- With balances that have a round weighing pan (102,105,108), position
the centering ring (101,103) on the pan retaining pin (409).
- Place the movable parts on the balance, depending on the model, e.g.
weighing pan (102,107,108), pan support (104), glass draft shield
cylinder (106), etc.
- The balance is now ready to operate.
SARTORIUS Basic plus
«; then press » « to initiate the
