Note:
Note:
- When installing the new PCB set, follow the instructions enclosed with the
PCBs (204) (33194-121-10) (33199-121-10) (33514-121-10)
(33518-121-10).
- See the board diagram for the position of the components and the solder
bridges.
- Place the new PCB set (204) in the base plate, position the PCBs, and
fasten the analog PCB (204b) and the data output PCB (204c) with the
fastening screws (D).
- Refasten the locking screws on the data output port.
- Reconnect all plugs (e.g. system connector- (ST.3), weight transapplication
sub-assembly plug, etc.) in the corresponding jacks on the analog
PCB (204b).
Having installed a new PCB set (204) with the basic data set, you must read
in the basic data set into the balance, using the Sartorius MC1 Server (version
4.4 and later). See the program description of the MC1 for instructions on this
procedure. You can then conclude the procedure for replacing the PCB set.
- Close the balance housing (see page 27).
- You must now perform the following adjustments (if you have not already
done so with the Sartorius MC1 Server (version 4.4 and later):
Linearity adjustment (see page 25),
External adjustment/calibration (see page 25),
Overwriting the internal calibration weight (see page 26).
- The balance is now ready to operate.
