Overwriting The Internal Calibration Weight - Sartorius Basic plus Service Manual

Note:
Caution:
Note:
26
The balance only accepts weight values within a tolerance range of approx.
2% of the nominal value. Deviations exceeding this tolerance range can only
be compensated using the Sartorius MC1-Server (tolerance approx. 50% of
the nominal value).
- Place the required weight in the middle of the weighing pan and, if you are
using a balance with a draft shield, close the draft shield.
- After the calibration weight is stored, the balance returns to the standard
weighing mode.
- After completing the adjustment, reset the "1 9" code setting in the balance
operating menu.

Overwriting the Internal Calibration Weight

The factory setting of the internal calibration weight is performed very
accurately:
- If overwriting becomes necessary, this indicates a mechanical or electrical
error !
- The balance must be allowed to warm-up (at least 4 hours) !
- The weights must be sufficiently accurate
(check the calibration certificate ! ).
There are various ways of overwriting the internal calibration weight on
Basic balances with brass-system (small).
plus
1. As described in this manual, or
2. Using the Sartorius MC1 Server (version 4.4 and later).
- Make sure that the menu code "1 9 3 - internal adjustment/calibration
accessible" is set (see page 13, "Balance Operating Menu Settings").
- Open the menu access switch, located at the back of the balance.
- If you have not done so already, perform the external adjustment/
calibration as described on page 25.
- Switch the balance off by pressing the »
- Hold down the »
» « key; hold down the »
left appears.
- Tare the balance by pressing »
adjustment/calibration function.
- The built-in, motorized adjustment/calibration weight is applied and then
removed automatically, the weight value is stored, and the balance then
returns to the standard weighing mode.
« key. .
« key and switch on the balance by pressing
« key until the display pictured at the
«; then press » « to initiate the
