3.3.4 Wi-Fi settings

The Wi-Fi module in the V-Tap may not be enabled by default. To
enable temporary do the following:
Power off and remove the SD card. Hold the button pressed during
power on and keep pressed for about 12 seconds until only the Blue LED
is on. Release the button, then Wi-Fi is available until the next reboot.
Once Wi-Fi is enabled, you can use your mobile phone or a laptop to
connect to the V-Tap over the air to access the settings:
•
Search for Wi-Fi apparatus on your smartphone or laptop, the V-Tap
name "V-Tap_PRI_xxxxxx" is then shown.
•
Select it and when asked for a password, use the 12 digits MAC
address of the unit, found on the bottom of the box. The first 6
digits of the MAC are always 000349 and the last 6 digits are also
part of the Wi-Fi name.
•
Disable mobile data on your phone (!), open a browser and enter the
IP address 192.168.55.66. The web login page should appear. Login
with username "admin" and password "admin".
The internal Wi-Fi works as an Access Point (AP) for web access and, at
the same time, can act as a station to connect to an external AP for the
tunnel function. DHCP is always enabled for Wi-Fi.
Wi-Fi Access Point
This enables or disables the web access using Wi-Fi permanently. The
temporary access
to connect with Wi-Fi can be changed in the
Wi-Fi Tunnel AP Name
Wi-Fi Tunnel AP Password
To setup a tunnel connection over Wi-Fi, the V-Tap must connect to
an external AP. In most of the cases this will be a router somewhere
in the building. The AP's name and password must be filled in here.
The Wi-Fi module can be disabled completely by turning the Wi-Fi Access
Point option off in the settings AND the Tunnel AP fields must be left
empty. All further access must then be done through a LAN cable.
Sending tunnel data with Wi-Fi is slower than using a LAN cable. So,
some delay must be considered before files are transferred.
V-Tap ISDN PRI Manual EN v1.23 Nov 2021
with the button is always available. The password
Login Password
© 2018-2021 Vidicode
field.
19
