3 Web interface and Settings

There are two ways to access the web interface of the V-Tap:

1) Connect a network cable to the LAN port on the unit. The other

side of the cable can be connected to a LAN or directly to a PC.

2) The built-in Wi-Fi module may not be enabled by default. To

enable temporary, power off and remove the SD card. Hold the

button pressed during power on and keep pressed for about 12

seconds until only the Blue LED is on. Release the button, then

Wi-Fi is available until the next reboot.

3.1 Access & IP address

In the case of using Wi-Fi, you need to enter the Wi-Fi access password

first, which is the 12 digits MAC address of the V-Tap, also found on the

bottom of the box. When connected (without internet), the IP address

192.168.55.66 must be entered in a browser. Remember to disabled

mobile data on your phone (!), else this IP address is not found.

In the case of using a cable, DHCP is enabled and the V-Tap can be

accessed with a browser by entering the address

In which

XXXX

are the last 4 digits of the MAC, as found on the bottom:

Default cable address:

Default web Username: admin

Default web Password:

Default Wi-Fi Password: 00034901019E <

Default Wi-Fi IP address: 192.168.55.66

If no DHCP server is available on the cable, it can be disabled temporary

by pressing the button for 1 second. The LED's will flash shortly and the

V-Tap can be accessed on the IP address 192.168.55.66
