3.3.2 Tunnel settings

Tunnel Server Address
Here you fill in the IP address or hostname of the Tunnel server that
is going to receive the recordings coming from the V-Tap ISDN.
Leaving this field empty will disable the Tunnel function all together,
in which case the V-Tap only stores recordings onto the SD card.
The receiving server can be an Apresa recorder or a PC running the
V-Archive software. In both cases, the V-Tap needs a license to allow
Tunnel data to be uploaded/streamed to the Tunnel server.
Without a license, the receiving server will discard the Tunnel data.
Tunnel Destination Port
The Tunnel protocol is based on the TCP protocol and that involves a
Destination Port and a Source Port. Both are numbers from 0 till
65535 that are included in each packet and are very important for
the receiving end of the Tunnel data. The receiving Tunnel server
must be setup to look for the same port number as is installed in this
Tunnel Destination Port.
Not all TCP port numbers are available for tunnelling, because some
are officially used by other protocols. For example, port 80 is used for
HTTP in all browsers to communicate over the World Wide Web. A
list of known port numbers can be found on the internet.
The default port number 2016 is not an official port and can be used
safely for this Tunnel protocol. The only drawback that comes by
using an unknown port is, that a firewall will block this port. For that
reason, it is important that any firewall that is passed by the Tunnel
stream must be setup right.
Firewalls must have a rule to let through TCP port 2016.
V-Tap ISDN PRI Manual EN v1.23 Nov 2021 © 2018-2021 Vidicode 16
