Overview

9910DA-3G-OM (V1.7)
This manual provides installation and operating instructions for the 9910DA
Multi-Rate DA with x4 Output Crosspoint cards (also collectively referred to
herein as the 9910DA).
Note: This manual covers the 9910DA-series, which consists of the:
- 9910DA-4Q-3G-RCK 3G/HD/SD-SDI Quad-Channel Multi-Rate Reclocking
DA with x4 Output Crosspoint (and non-reclocking version 9910DA-4Q-3G)
- 9910DA-2Q-3G-RCK 3G/HD/SD-SDI Dual-Channel Multi-Rate Reclocking
DA with x4 Output Crosspoint (and non-reclocking version 9910DA-2Q-3G)
- 9910DA-1Q-3G-RCK 3G/HD/SD-SDI Single-Channel Multi-Rate
Reclocking DA (and non-reclocking version 9910DA-1Q-3G)
These cards vary primarily as having (or not having) a multi-input crosspoint,
and the I/O size of the crosspoint. Where differences exist, the differences are
described for each individual model.
This manual consists of the following chapters:
Chapter 1, "Introduction" – Provides information about this manual
•
and what is covered. Also provides general information regarding the
9910DA.
Chapter 2, "Installation and Setup" – Provides instructions for
•
installing the 9910DA in a frame, and optionally installing a 9910DA
Rear I/O Module.
Chapter 3, "Operating Instructions" – Provides overviews of
•
operating controls and instructions for using the 9910DA.
This chapter contains the following information:
Manual Conventions (p. 1-2)
•
Safety Summary (p. 1-3)
•
9910DA Functional Description (p. 1-4)
•
Technical Specifications (p. 1-6)
•
Warranty and Service Information (p. 1-7)
•
Contact Cobalt Digital Inc. (p. 1-8)
•
9910DA PRODUCT MANUAL
Chapter 1
Introduction
Chapter 1
1-1
