Technical Specifications

Table 1-1 Technical Specifications
Item
Part number, nomenclature
Installation/usage environment
Power consumption
Installation Density
Environmental:
Operating temperature:
Relative humidity (operating or storage):
Frame communication
Indicators
3G/HD/SD-SDI / ASI Inputs
Receive Performance (Cable Length;
Belden 1694A)
3G/HD/SD-SDI / ASI Outputs
1-6
Table 1-1 lists the technical specifications for the 9910DA cards.
• 9910DA-4Q-3G-RCK 3G/HD/SD/ASI Quad-Channel Multi-Rate
Reclocking DA with x4 Output Crosspoint card
• 9910DA-4Q-3G 3G/HD/SD/ASI Quad-Channel Multi-Rate DA
with x4 Output Crosspoint (Non-Reclocking) card
• 9910DA-2Q-3G-RCK 3G/HD/SD/ASI Dual-Channel Multi-Rate
Reclocking DA with x4 Output Crosspoint card
• 9910DA-2Q-3G 3G/HD/SD/ASI Dual-Channel Multi-Rate DA
with x4 Output Crosspoint (Non-Reclocking) card
• 9910DA-1Q-3G-RCK 3G/HD/SD/ASI Single-Channel Multi-Rate
Reclocking DA card
• 9910DA-1Q-3G 3G/HD/SD/ASI Single-Channel Multi-Rate DA
(Non-Reclocking) card
Intended for installation and usage in frame meeting openGear™
modular system definition.
< 3 Watts maximum
Up to 10 cards per 20-slot frame
32° – 104° F (0° – 40° C)
< 95%, non-condensing
10/100/1000 Mbps Ethernet with Auto-MDIX.
Card edge display and indicators as follows:
• Status/Error LED indicator
• Input Presence LED indicators
(4) 75Ω coaxial inputs; max (A thru D)
SDI Formats Supported: SMPTE 259M, SMPTE 292M,
SMPTE 424M
SDI Return Loss: >15 dB up to 1.485 GHz; >10 dB up to
2.970 GHz
3 Gbps: 120m
1.485 Gbps: 160m
143-360 Mbps: 400m
(4x4) 75Ω coaxial outputs (16 total)
Signal Level: 800 mV nominal
Return Loss: >15 dB at 5 MHz - 1.485 GHz Jitter (wideband): HD
< 0.2 UI
