Installing the 9910DA Into a Frame Slot

2-4
CAUTION
Note: If installing the 9910DA in a slot with no rear I/O module, a Rear
I/O Module is required before cabling can be connected. Refer to Installing a
Rear I/O Module (p. 2-5) for rear I/O module installation procedure.
CAUTION
If required, make certain Rear I/O Module(s) is installed before installing the
9910DA into the frame slot. Damage to card and/or Rear I/O Module can occur
if module installation is attempted with card already installed in slot.
Note: Check the packaging in which the 9910DA was shipped for any extra items
such as a Rear I/O Module connection label. In some cases, this label is
shipped with the card and to be installed on the Rear I/O connector bank
corresponding to the slot location of the card.
Install the 9910DA into a frame slot as follows:
Determine the slot in which the 9910DA is to be installed.
1.
Open the frame front access panel.
2.
While holding the card by the card edges, align the card such that the
3.
plastic ejector tab is on the bottom.
Align the card with the top and bottom guides of the slot in which the
4.
card is being installed.
Gradually slide the card into the slot. When resistance is noticed, gently
5.
continue pushing the card until its rear printed circuit edge terminals
engage fully into the rear I/O module mating connector.
CAUTION
If card resists fully engaging in rear I/O module mating connector, check for
alignment and proper insertion in slot tracks. Damage to card and/or rear I/O
module may occur if improper card insertion is attempted.
Verify that the card is fully engaged in rear I/O module mating
6.
connector.
9910DA PRODUCT MANUAL
Installing the 9910DA Into a Frame Slot
This device contains semiconductor devices which are
susceptible to serious damage from Electrostatic
Discharge (ESD). ESD damage may not be immediately
apparent and can affect the long-term reliability of the
device.
Avoid handling circuit boards in high static environments
such as carpeted areas, and when wearing synthetic fiber
clothing. Always use proper ESD handling precautions
and equipment when working on circuit boards and
related equipment.
9910DA-3G-OM (V1.7)
