- Page 1 Cobalt Digital Inc. 9231 Analog Video Distribution Amplifier w/ Differential Input, Clamping and Cable Equalization Owner’s Manual Cobalt Part Number: 9231 v.1.3 9231 Manual V.1.3 2/14/2014...
- Page 2 The material in this manual is furnished for informational use only. It is subject to change without notice and should not be construed as a commitment by Cobalt Digital Inc. Cobalt Digital Inc. assumes no responsibility or liability for errors or inaccuracies that may appear in this manual.
-
Page 3: Symbol Meanings
Important Regulatory and Safety Notices Before using this product and any associated equipment, refer to the “Important Safety Instructions” listed below so as to avoid personnel injury and to prevent product damage. Products may require specific equipment, and /or installation procedures be carried out to satisfy certain regulatory compliance requirements. - Page 4 US FCC Part 15 This equipment has been tested and found to comply with the limits for a class A Digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
-
Page 5: Environmental Information
To avoid the potential release of those substances into the environment and to diminish the need for the extraction of natural resources, Cobalt Digital Inc.encourages you to use the appropriate take-back systems. These systems will reuse or recycle most of the materials from your end-of-life equipment in an environmentally friendly and health conscious manner. - Page 6 Introduction This chapter contains the following sections: • Overview • Functional Block Diagram • Features • Documentation Terms...
-
Page 7: Functional Block Diagram
The 9231 is an analog video distribution amplifier with a differential input designed for broadcast use. It has one input and can provide up to eight outputs. The 9231 can be addressed through Dashboard to report card status and activate features. -
Page 8: Installation And Setup
Unpacking Unpack each 9231 you received from the shipping container, and check the contents against the packing list to ensure that all items are included. If any items are missing or damaged, contact your sales representative or Cobalt Digital Inc. directly. -
Page 9: Rear Module Installation (Optional)
Rear Module Installation (Optional) If you are installing the card into a slot with no rear module, you should have ordered and received one of the RM-9231-B modules. You will need to install it in a 20-slot frame before you can connect cables. - Page 10 Rear Module Options RM20-9231-B RM20-9231-A/S RM20-9231-B/S Figure 2. 9231 Rear Modules...
-
Page 11: Board Installation
1. Refer to the User Manual of the frame to ensure that the frame is properly installed according to instructions. 2. After selecting the desired frame installation slot, hold the 9231 card by the edges and carefully align the card edges with the slots in the frame. Then fully insert the card into the frame until the rear connection plugs are properly seated on the midplane and rear module. -
Page 12: User Controls
EQ (0 - 300 m) Figure 3. Card-edge User Controls Level The level control is used to adjust the output levels of the 9231. This potentiometers gives precise control of the output signal over a +/-3 dB range EQ(0 – 300m) -
Page 13: Jumper Settings
LEDs The front-edge of the card features LEDs that display the status of the input signals. Descriptions are provided in the following table: Color Location Display and Description When illuminated there is a valid analog signal at the input. Top of the Green SYNCH card... -
Page 14: Remote Control
REMOTE CONTROL DashBoard Control This card may be monitored by a remote computer through DashBoard the free configuration monitoring software.. With DashBoard installed on your computer the following menus are available when interrogating an 9231 card: MENU ITEM DISPLAY DESCRIPTION... -
Page 15: Specifications
Output Impedance(8 splits) 75 Ohm Output level 1Vp-p, terminated GENERAL Power Requirements +12 V,120 mA, -7,5V, 55mA Dimensions 3.025" high x 12.800" deep Weight approx.0.115 kg (0.252 lbs) Cobalt Digital Inc. reserves the right to change performance specifications without prior notice. -
Page 16: Warranty And Repair Policy
(1) year. Cobalt Digital Inc.'s (“Cobalt”) sole obligation under this warranty shall be limited to, at its option, (i) the repair or (ii) replacement of the product, and the determination of whether a defect is covered under this limited warranty shall be made at the sole discretion of Cobalt. -
Page 17: Ordering Information
RM20-9231-B Rear Module (20-slot Frame Rear I/O Module (Standard Width) 1 Video Input BNC, 1 Looped Video Output BNC, 8 Video Output BNCs) RM20-9231-A/S Rear Module (20-slot Frame Rear I/O Module (Split) 1 Video Input BNC, 4 Video Output BNCs per card) - Page 18 217 • 344 • 1245 General Information sales@cobaltdigital.com E-MAIL Technical Support support@cobaltdigital.com POSTAL 2406 E. University Ave. Cobalt Digital Inc. Urbana, IL 61802 SERVICE Visit Us Please visit us at our website for: • Company information • Related products and full product lines •...
