Hold top of Rear I/O Module flush against
2
frame chassis and start the captive screw.
Lightly tighten captive screw.
Figure 2-3 Rear I/O Module Installation
9910DA PRODUCT MANUAL
Installing a Rear I/O Module
Align and engage mounting tab on Rear
1
I/O Module with the module seating slot
on rear of frame chassis.
9910DA-3G-OM (V1.7)
