Overview

Card-Edge Switches and Monitoring

9910DA-3G-OM (V1.7)
Installation and Setup
Chapter 2
This chapter contains the following information:
Card-Edge Switches and Monitoring (p. 2-1)
•
Installing the 9910DA Into a Frame Slot (p. 2-4)
•
Installing a Rear I/O Module (p. 2-5)
•
CAUTION
This device contains semiconductor devices which are
susceptible to serious damage from Electrostatic
Discharge (ESD). ESD damage may not be immediately
apparent and can affect the long-term reliability of the
device.
Always use proper ESD handling precautions and
equipment when working on circuit boards and related
equipment.
Figure 2-1 shows and describes the card-edge switches which can be used to
provide limited card control without requiring a remote control connection
(local control).
