Card-Edge Switch
OFF (up)
ON (down)
SW1 SW2
OFF
ON
— ON
— ON
— OFF
Note: • When using card-edge control, DA modes are limited to inputs listed.
When using remote control, inputs to the four quad or dual DA blocks
can be sourced as desired and as supported by rear I/O module
connector count.
• When using card-edge control, displayed DashBoard routing settings
may not reflect actual fixed card-edge routing.
• SW4 is reserved.
• Setting switch SW1 to local locks out remote control of the card.

Input/Output Routing With Card in Card-Edge (Local) Control Mode

2-2
9910DA
SW3 Mode
Remote Control
— —
Local (card-edge) Control
ON Quad 1x4 DA (uses IN A thru IN D)
(-4Q models only)
OFF Dual 1x8 DA (uses IN A and IN B)
(-4Q and -2Q models only)
— Single 1x16 DA (uses IN A)
Figure 2-1 9910DA Card-Edge Switches
When the card is set for card-edge (local) control, only fixed quad 1x4, dual
1x8 (- 4Q and
dedicated input and output ports. When using any of these fixed modes, the
rear I/O module used must be compatible with the mode. (See 9910DA Rear
I/O Modules (p. 2-7) for rear module details.) Figure 2-2 shows the fixed
routing available using local control and compatible rear modules.
9910DA PRODUCT MANUAL
Card-Edge Switches and Monitoring
Status/Error
Indicators
-2Q models only), and single 1x16 routing is available using
Input Lock
Indicators
