J2: 14-Pin: Power Board (Flex Cable)

Pin #
Signal
1
+24VDC
2
+24VDC
3
+24VDC
4
PGND
5
PGND
6
PGND
7
TXP
8
RXP
9
COMP
10
MRESET\
11
PRNTR LMP+
12
PRNTR LMP-
13
+VRESET
14
N/C

Table 9 Power Board to Connector Board (flex cable), J2

Page 20
Series 700 Maintenance Manual
Description
Parameters
Printer Voltage
0.5 A maximum (each)
Printer Ground
0.5 A maximum (each)
Printer Transmit
Per RS-232C
Printer Receive
Printer Common
Master Reset
Active Low Signal - Optically Isolated
Lamp Voltage
0.5 A maximum (each)
Lamp Return
13 VDC ± 10% @15 mA
Reset Voltage
No Connect
All connector views are shown
from the PCB component side.
Rev H
Vin(H) 13 VDC
Vin(L) 0.3-1.2 V @15 mA
